Dwyer 1950G-0-b-24 Explosion-proof Differential Pressure Switch 24 Vdc Ip54
Dwyer Instruments, Inc.
Cat No: 1950G-0-b-24
S813856 A48X
Cl.I Div.1 Gr. A, B, C, D
Cl.Ii Gr. E, F, G
Cl.Iii
Ip54 (Gr. A Is Only)
Rain Tight (Encl.3)
Electrical Rating:
10A 120, 240Vac, 28 Vdc Resistive
50Ma, 125 Vdc Resistive
Supply Voltage: 24 Vdc
Use 95C Conductors
Max Press: 45 In Wc (.11 Bar)
Surge Press: 10 Psi (.69 Bar)
Tamb: 0F To 140F (-17.7C To 60)
Ii 2 G
Kema 03 Atex 2402 X
Ex D Iib+H2 T6 Gb (40C Less Than Ta Less Than 60C)
Iecex Dek Ii.0092X
Electrical Entry 1/2 Npt
12.5-20.5Mm
(0.49-0.81)
U.S.A.
Weight: 1.640 Kg
