Overcurrent characteristics of MCCB have been set to the ambient temperature of 40 degrees celsius. If the ambient temperature is less or more than 40 degrees celsius, the overcurrent characteristics can be changed.
If the internal temperature of the MCCB is over 40 degrees, thermal damage to the insulating material inside the MCCB can occur causing the circuit breaker to trip at an early stage. When applying ambient temperatures at higher than 40 degrees celsius

Specification:

• CAPACITANCE
• Breaking capacity IEC 60947-2(IcuIcs) @415V Icu/Ics : 16 KA/16KA
• POWER
• Ampere Range 16, 20, 32, 40, 50, 63, 75 & 100 Amps
• SUMMARY
• Rated Current 30 A,60A,100A
• HARDWARE FEATURES
• Number of Poles 3-poles
• TECHNICAL SPECIFICATION
• Insulation Voltage 750V
• GENERAL SPECIFICATION
• Frame Rate 100 (AF)
• Series HG Series

Package Includes:

1 x Molded Case Circuit Breakers HGM100E 3P 100A HYUNDAI
