NBB4-12GM50-E0-V1 Pepperl+Fuchs, M12,NPN-NO Inductive Sensor 65mm Length,10 ? 30 V dc

$9.45 $15.75

NBB4-12GM50-E0-V1 Pepperl + Fuchs, M12 , NPN-NO Inductive Sensor 65mm Length, 10 ? 30 V dc in pakistan BR1933 NBB4-12GM50-E0-V1 Pepperl+Fuchs, M12,NPN-NO Inductive Sensor 65mm Length,10 ? 30 V dc in Pakistan. Specification: Switching function Normally open

Qty:

Payment:

Payment Option Image

NBB4-12GM50-E0-V1 Pepperl + Fuchs, M12 , NPN-NO Inductive Sensor 65mm Length, 10 ? 30 V dc in pakistan BR1933

NBB4-12GM50-E0-V1 Pepperl+Fuchs, M12,NPN-NO Inductive Sensor 65mm Length,10 ? 30 V dc in Pakistan.

Specification:

  • Switching function Normally open (NO)
  • Output type NPN
  • Rated operating distance 4 mm
  • Installation flush
  • Output polarity DC
  • Assured operating distance 0 … 3.24 mm
  • Nominal ratings
  • Operating voltage 10 … 30 V
  • Switching frequency 0 … 800 Hz
  • Hysteresis typ. 5%
  • Reverse polarity protection reverse polarity protected
  • Short-circuit protection pulsing
  • Voltage drop ? 3 V
  • Operating current 0 … 200 mA
  • Off-state current 0 … 0.5 mA typ. 0.1 A at 25 C
  • No-load supply current ? 15 mA
  • Switching state indicator Multihole-LED, yellow
  • Functional safety related parameters

Features:

  • MTTFd 1679 a
  • Mission Time (TM) 20 a
  • Diagnostic Coverage (DC) 0 %
  • Approvals and certificates
  • UL approval cULus Listed, General Purpose
  • CSA approval cCSAus Listed, General Purpose
  • CCC approval CCC approval / marking not required for products rated ?36 V
  • Ambient conditions
  • Ambient temperature -25 … 70 C (-13 … 158 F)
  • Mechanical specifications
  • Connection type Connector M12 x 1 , 4-pin
  • Housing material brass, nickel-plated
  • Sensing face PBT
  • Housing diameter 12 mm
  • Degree of protection IP67

Packages Include:

1 x NBB4-12GM50-E0-V1 Pepperl+Fuchs, M12,NPN-NO Inductive Sensor 65mm Length,10 ? 30 V dc
