The OMRONEE-SX670 is a type of sensor, specifically a slot-type photomicro sensor, used to detect objects passing through a small gap. It operates using a through-beam method, meaning it has a light emitter and receiver, and an object breaking the beam is detected. This sensor is manufactured by Omron, has an NPN output, and can be set to either Dark-ON or Light-ON operation. It’s designed for a DC power supply ranging from 5V to 24V, and it’s commonly used in automation and control systems for tasks like object detection, position sensing, and counting.

Features of OMRONEE-SX670 Micro Photoelectric Sensor:

• Slot-type design: The sensor has a U-shaped structure with a slot.
• Through-beam sensing: Detects objects by sensing when they interrupt a light beam.
• Sensing distance: 5mm slot width.
• Light source: Infrared LED.
• Output type: NPN output.
• Operation mode: Selectable between Dark-ON and Light-ON.
• High response frequency: Up to 1 kHz.
• Compact size
• Easy operation monitoring: Bright light indicator.
• Wide operating voltage range: 5 to 24 VDC.
• Housing material: PBT (Polybutylene Terephthalate) case.
• Connector type: Connector.

Specifications of OMRONEE-SX670 Micro Photoelectric Sensor:

• Sensing method: Through-beam with slot
• Sensing distance: 5 mm
• Light source: Infrared LED
• Power supply: 5 to 24 VDC
• Output type: NPN
• Operation mode: Dark-ON/Light-ON selectable
• Response time: 0.17 ms
• Operating temperature: -25 to +55C
• IP rating: IP50

Uses:

• Object detection: Detecting the presence or absence of objects.
• Position sensing: Determining the position of an object.
• Counting: Counting objects as they pass through the sensor’s slot.
• Motion detection: Detecting movement.
• Edge detection: Detecting the edge of an object.
• Part inspection: Verifying the presence or correct positioning of parts.
• Automated assembly lines: Used in manufacturing for quality control and part handling.
• Packaging machinery: Monitoring material handling and product flow.
• Conveyor systems: Detecting objects on a conveyor belt.
• Robotics: Position and movement control

Benefits:

• Accurate detection: Provides reliable and accurate object detection.
• Fast response: High-speed response for quick detection of fast-moving objects.
• Versatile operation: Selectable Dark-ON/Light-ON operation for different application needs.
• Wide voltage range: Compatible with various power supplies.
• Compact design: Small size allows for installation in space-constrained areas.
• Durable construction: Robust housing for use in industrial environments.
• Easy installation:
• Non-contact sensing: Does not require physical contact with the object being detected.
• Long lifespan:
• Cost-effective

Package includes:

• 1x OMRONEE-SX670 Micro Photoelectric Sensor
