Proximity Sensor high RPM 8mm tip size 1mm sensing distance PNP in Pakistan BR1920

Description:

• 2-Wire, 3-Wire, DC, and AC/DC Multiple Range Sensor Models
• Manufactured to Take Physical and Environmental Abuse
• Designed with Stainless Steel Barrel and New Potting Compound for Robust, High Temperature, High Pressure Washdown, as Well as Intense Shock and Vibration Applications
• Unmatched High Noise Immunity Eliminates Problems Associated with Electrical Noise (All Models >20V/Meter)
• 360 Output Status Indicator is Visible from Any Angle and in Any Light Condition
• Resettable Short Circuit Protection and Reverse Polarity in Select Models
• Wide Temperature Range -25 to 70C (-13 to 158F) on Cable, Micro-Style Connections

Specifications:

Operating Voltage 40 to 250 Vac/20 to 250 Vdc 6 to 48 Vdc Maximum Load Current 250 mA @ 25C
200 mA @ 70C 500 mA @ 6 to 30 Vdc Switching Frequency 60 Hz 12 mm: 1000 Hz; 18 mm: 800 Hz; 30 mm: 500 Hz Leakage Current ?2.0 mA ?100 A Voltage Drop ?12V @ <10mA ?4V @ > 25mA ?2.5V Holding Current 5 mA min Burden Current ?10 mA Protection Resettable short circuit
overload protection Auto reset Switching Hysteresis <15% rated sensing distance Repeat Accuracy Shielded Models: <1% sensing distance; Unshielded and extended range: <3% Time Delay Before Availability <200 mS

Package Includes:

1 X Proximity Sensor high RPM 8mm tip size 1mm sensing distance PNP
